Key Features:
01
1. Sturdy front aluminum alloy bezel enhanced with sandblasting and hard anodizing for ultimate UV-protection and discoloration resistance. Ensures full IP67 waterproof and dustproof integrity, complete with a waterproof connector.
02
2. State-of-the-art industrial LCD panel offering full viewing angles and an incredible 1000 nits sunlight readability. Equipped with a light sensor that automatically adjusts brightness for optimal visibility.
03
3. Advanced 10-point PCAP touch panel covered with 2mm chemically strengthened tempered glass boasting a 7H surface hardness and anti-glare treatment for superior touch accuracy and durability.
04
4. Utilizes the EETI waterproof solution, ensuring touch functionality remains flawless even in the presence of water droplets on the screen.
05
5. Constructed with industrial-grade components designed for 24/7 continuous operation. Reliable in extreme temperature ranges from -20°C to 70°C (-4°F to 158°F).
06
6. Cutting-edge optical bonding between the touchscreen and LCD enhances display clarity and durability.
07
7. The front frame and rear shell are expertly sealed with waterproof tape, allowing disassembly for inspection and maintenance without compromising its waterproof capabilities.
Specification
|
LCD panel( IPS screen) |
|
|
Panel size |
15.6" 18.5" 21.5" 23.6" (16:9) |
|
Native Resolution |
1920*1080 |
|
Brightness (cd/m²) |
250cd/m2 1000cd/m2 1500cd/m2 Optional |
|
Contrast ratio |
1000:1 |
|
View angle |
89°/89°/89°/89° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
10 points Projected capacitive touch |
|
Touch Interface |
USB |
|
Signal Ports |
|
|
VGA |
1×IP67 VGA |
|
USB |
1xIP67 USB for touch |
|
HDMI |
1xIP67 HDMl |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
|
Support OS |
Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android, Raspberry Pi ect |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V |
|
Working voltage |
DC 12V |
|
Power consumption |
≤30W |
|
Operating Environment |
|
|
Temperature Range |
operating: -20 to 60°C, storage :-20 to 80°C |
|
Relative humidity |
operating: 10% to 90% , storage :5% to 90% |
|
Packing Details |
|
|
Packing detail |
1pcs/box 2pieces/carton |
|
Accessories |
IP67 Power adapter, ip67 *HDMI cable, IP67 USB touch cable, mountable stand for boat, optional |
|
Others |
|
|
Warranty |
1 year warranty |
