IP68 vs. IP65 Industrial Displays: A Detailed Comparison
When selecting an industrial monitor for harsh environments, understanding the Ingress Protection (IP) rating is crucial. Two common ratings-IP65 and IP68-offer different levels of protection against dust and water. Below is a detailed comparison to help you choose the right solution for your application.
1. Protection Level Overview
IP65:
Dust-proof: Completely protected against dust ingress (no harmful deposits).
Water-resistant: Guards against low-pressure water jets (6.3mm nozzle) from any direction.
Limitation: Not suitable for prolonged submersion or high-pressure cleaning.
IP68:
Dust-proof: Same as IP65-fully dust-tight.
Waterproof: Can withstand continuous immersion underwater (depth/time specified by the manufacturer, typically 1m for 30+ minutes).
Ideal for: Submersion-prone or high-humidity environments (e.g., marine, food processing, outdoor use).
2. Key Differences
| Feature | IP65 | IP68 |
|---|---|---|
| Dust Proof | Yes (6) | Yes (6) |
| Waterproof | Jet-resistant (5) | Submersion-proof (8) |
| Durability | Moderate | Extreme |
| Applications | Indoor factories, warehouses | Outdoor, washdown areas, oil & gas |
| Cost | Lower | Higher |
3. Application Scenarios
01
Choose IP65 if:
Your environment requires protection against dust and occasional splashes (e.g., indoor machinery, control panels).
Budget constraints exist, and submersion isn't a risk.
02
Choose IP68 if:
The display may face submersion, high-pressure washdowns, or extreme humidity (e.g., food processing, chemical plants, offshore rigs).
Long-term reliability in wet conditions is critical.
4. Other Considerations
Sealing Materials: IP68 displays often use robust gaskets or epoxy resin, impacting weight and repairability.
Temperature/chemical resistance: Verify additional certifications (e.g., NEMA, IK rating for impact).
Conclusion
While both IP65 and IP68 displays excel in dust resistance, IP68 is superior for wet or submerged environments. Evaluate your operational conditions and total cost of ownership to make the optimal choice.
