Features:
1. Meticulously crafted with an aluminum alloy face frame paired with a sophisticated heat sink sandblasting oxidation process, it offers supreme anti-UV and anti-discoloration treatments. Achieve complete IP67 waterproof integrity for the entire device.
2. Experience versatility with two refined installation methods: choose from front frame embedding or side bracket options. The design includes upper and lower frames equipped with elegant, removable aluminum strip devices to seamlessly cover installation holes, complemented by an all-aluminum installation bracket for robust stability.
3. Our industrial-grade LCD screen provides a full viewing angle and an impressive 1000 brightness level, perfect for sunlight visibility. Enjoy dual brightness adjustment methods with both OSD and remote control options.
4. Featuring a 10-point capacitive touch screen, it's armored with 2mm chemically strengthened tempered glass, boasting a hardness level of 7H and an AG anti-glare surface treatment for optimal clarity and durability.
5. The EETI touch control solution ensures impeccable functionality, even when water droplets grace the surface of the touch screen.
6. Benefit from superior optical bonding between the LCD and touch screen, enhancing display quality and durability
7. Built with top-tier industrial-grade components, this device guarantees 7x24 hours of continuous operation, while supporting a wide temperature range of -20ºC to 70ºC.
8. Featuring a meticulously designed sealing system with waterproof rubber strips around the front frame and rear shell, the machine allows for easy disassembly for inspection and repair without compromising its waterproof integrity.
Specification
|
LCD panel( IPS screen) |
|
|
Panel size |
15.6" 18.5" 21.5" 23.6" (16:9) |
|
Native Resolution |
1920*1080 |
|
Brightness (cd/m²) |
250cd/m2 1000cd/m2 1500cd/m2 Optional |
|
Contrast ratio |
1000:1 |
|
View angle |
89°/89°/89°/89° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
10 points Projected capacitive touch |
|
Touch Interface |
USB |
|
Signal Ports |
|
|
VGA |
1×IP67 VGA |
|
USB |
1xIP67 USB for touch |
|
HDMI |
1xIP67 HDMl |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
|
Support OS |
Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android, Raspberry Pi ect |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V |
|
Working voltage |
DC 12V |
|
Power consumption |
≤30W |
|
Operating Environment |
|
|
Temperature Range |
operating: -20 to 60°C, storage :-20 to 80°C |
|
Relative humidity |
operating: 10% to 90% , storage :5% to 90% |
|
Packing Details |
|
|
Packing detail |
1pcs/box 2pieces/carton |
|
Accessories |
IP67 Power adapter, ip67 *HDMI cable, IP67 USB touch cable, mountable stand for boat, optional |
|
Others |
|
|
Warranty |
1 year warranty |
