10.4 inch IP65 High Brightness Monitor
1. PCAP capacitive touch Screen Monitor
2. True Flat Design
3. 1000nits High Brightness
4.Use Optical Bongding design
5. can choose Light Sensor or use remote control
6. Anti Glare and Anti UV film is Optional to choose
7.Aluminum front and middle case, metal back case
Multiple interfaces available
1. VGA HDMI DVI, USB For touch
2. DV12V Input, DC9-36V Phoenix Terminal Optional
3. Audio in and out
4. DP or 2HDMI is avaible too if needed
The 10.4 inch monitor with metal back case
1. metal Back case
2. many holes design, better for heat sink
3. 2 speakers
4. 100x100 vesa mounting holes
the 10.4 inch High Brightness Monitor with Embedded install holes, suitable to install the monitor into the kiosk, such as the payment kiosk, the smart lockers, the bank and hotel self service kiosk, the Bottle recycling machine and so on.
the monitor is IP65 Front case, can stick the gasket to prevent the waterproof enter into the kiosk after installed into the kiosk
The Industrial IP65 High Brightness Monitor with Optical Bonding, Panel Mount design suitable to used to the below areas.
The company conducted a competitive advantage analysis to identify its strengths and weaknesses compared to its rivals.
1. Industrial Automation & Manufacturing
Applications:
CNC Machine Control – Operator interface for lathes, mills, and robotic arms.
SCADA/HMI Systems – Real-time monitoring of production lines.
Quality Inspection – Integrated into vision systems for defect detection.
2. Food & Beverage Processing
Applications:
Washdown Control Panels – Hygienic interfaces for packaging lines.
Bottling & Labeling Machines – Sealed against water/chemical splashes.
3. Oil, Gas & Energy
Applications:
Pipeline Monitoring – Displays pressure/temperature data.
Power Plant Control Rooms – Grid management dashboards.
4. Transportation & Fleet Management
Applications:
Vehicle Telematics – Dashboard displays for trucks/AGVs.
Railway Signaling – Control panels in train cabins.
5. Medical & Laboratory Equipment
Applications:
Surgical Monitors – Sterile displays for operating rooms.
Diagnostic Devices – Blood analyzer/PCR machine interfaces.
6. Military & Aerospace
Applications:
Command Center Consoles – Tactical mission control.
Aircraft Avionics – Cockpit instrumentation.
7. Outdoor & Public Kiosks
Applications:
Ticketing Machines – Subway/airport self-service terminals.
Digital Signage – Weatherproof advertising displays.
other
100% Testing Before Delivery
1.Display Test
2.Static Test
3.High & low temperature
4.Drop Test
5.Anti-vibrationtest
6.Aging Test
Exhibitions Link the Globe, Cooperation Benefits All
We actively participate in exhibitions across various regions, and through exchanges and negotiations, we have established friendly cooperative relationships with numerous partners. Today, our customers are distributed all over the world.
First-class professional team for you to recommend products more in line with your needs. Perfect after-sale services exempt your worries.
Our address
No.5F, Building 24, Longbi Industry City, Bantian Street, Longgang District, Shenzhen City, Guangdong Province, China
Phone Number
+86-755-28447130
+8613632535154
sales@bestview.cc
| industrial touchscreen pc,panel pc windows 10,marine monitor,onlogic panel pc,touch panel pc,industrial panel pc windows 10,industrial monitor direct,rugged touch screen monitor,industrial touch screen computer,industrial screens,panel mount pc. |
elo industrial touch screen,advantech panel pc,all in one touch screen,all in one desktop computer touch screen,ip69k computer,ip65 monitor,industrial all in one pc,industrial touch panel,sensor panel pc,best all in one touch screen computer
|
LCD panel( IPS screen) |
|
|
Panel size |
10.4" (4:3) |
|
Native Resolution |
1024x768 |
|
Brightness (cd/m²) |
1000nits |
|
Contrast ratio |
1000:1 |
|
View angle |
85°/85°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
10 points Projected capacitive touch |
|
Touch Interface |
USB |
|
Signal Ports |
|
|
VGA |
1×VGA |
|
USB |
1xUSB for touch |
|
HDMI |
1xHDMI |
|
DVI |
1XDVI |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
|
Support OS |
Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android, Raspberry Pi ect |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V |
|
Working voltage |
DC 12V 9-36V Optional |
|
Power consumption |
≤30W |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 60°C, storage :-20 to 70°C |
|
Relative humidity |
operating: 10% to 90% , storage :5% to 90% |
|
Packing Details |
|
|
Packing detail |
1pcs/box 3pieces/carton |
|
Accessories |
Power adapter, VGA cable,HDMI cable,DVI cable, USB touch cable, Stander optional |
|
Others |
|
|
Warranty |
1 year warranty |
