Feature
01
1. Durable materials: Aluminum alloy frame & Metal back cover, Corrosion and oxidation resistance.
02
2. Simple Installation: Wall mounted / desktop stand / embedded etc installations, plug and play. No need to debug.
03
3. Structure crafts: Private mould design, pure flat and slim style, new backlight integrated structure, good sealing, surface IP65 waterproof.
04
4. Stable performance: Each unit undergoes multiple tests such as whole machine aging, temperature and humidity testing, static electricity detection, vibration, high voltage, touch click and display to ensure stable quality and support 7*24H work.
05
5. Strict quality control: The monitors have undergone multiple tests such as 48-hour ageing, electrostatic testing, vibration, voltage/electronic load test, voltage withstand test, touch/calibration test, controlled high temperature test, constant temperature and humidity test, controlled drop test.
06
6. OEM services：Flexible to add serial and USB ports (color,logo,4G module,packaging, etc).
18.6 Inch embedded Monitor Sample Availability & Policy:
Buyer covers the shipping cost, Sample fee can be deducted from the first order
OEM & ODM sample lead time to be discussed.
How about our after-sales service?
01
1) Provide 1% spare parts and Service manual .
2) Guarantee 1 year warranty.
02
3) Do OEM/ODM services: design color box, print logo, make start-up logo
4) Offer Pictures relevant to orders production.
18.5 Inch Open Frame Screen Monitor Product Compliance :
All of Products can be compliant with RoHS, CE, FCC.
Can also do WEEE / REACH Complaint.
Recycle Material Compliant
UL / CSA Complaint can be done upon requirement
PSE / NCC can be done upon requirement
18.5 Inch embedded Screen Monitor Warranty & Spare parts Conditions :
1. Products comes with 1 Year Warranty
2. Offer Premium Quality for Customer to make better profits
3. High Quality Standard
4. Products makes Customer Best Seller Product
5. Provide Best Product for futher sales
6. Sell Original Authentic Product to Customer
7. Products are Environment Friendly Products.
8. Give Best Service Guarantee to Customer
9. Believe Customer Satisfaction and Maintain Promise offered to Customer.
|
LCD panel( IPS screen) |
|
|
CPU |
Intel® Celeron J1900 2.0GHz, Quad cores, fanless |
|
Intel® Core i3-3217U 1.8GHz dual cores, with fan |
|
|
Intel® Core i5-3317U 1.7GHz dual cores, with fan, i5-6th |
|
|
Memory |
8GB DDR3 ( Max. 32G) |
|
Hard Drive Optional |
SSD: 32GB,64GB,128GB, 256GB |
|
HDD: 160GB,320GB,500GB,1TB |
|
|
Graphics |
CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
|
Audio |
Realtek ALC662, High Definition Audio (HD), Line in, Line out |
|
Network |
1×Realtek RTL 8111F Gigabit Ethernet controller |
|
Wifi |
Optional |
|
4G module |
Optional |
|
I/O Interface |
2×USB2.0, 2×USB3.0,1×Lan(RJ45),1 x COM(RS232/Serial), 1×VGA/HDMI/Audio OUT/POWER DC |
|
Opetation System |
Windows 7/8/10/Linux |
|
LCD panel |
|
|
Panel size |
18.5" (16:9) |
|
Resolution |
1920X1080 |
|
Brightness (cd/m²) |
350 cd/m² |
|
Response time |
15ms |
|
Contrast ratio |
1000:1 |
|
View angle |
89°/89°/89°/89° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
10 points Projected capacitive touch |
|
Touch Interface |
USB |
|
Touch response time |
<8ms |
|
Luminousness |
75-85% |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V |
|
Working voltage |
DC 12V |
|
Power consumption |
≤30W |
|
Operating Environment |
|
|
Temperature range |
operating: -25 to 75°C, storage :-30 to 80°C |
|
Relative humidity |
5%~95% @ 40° C, non-condensing |
|
Vibration |
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
|
Packing Details |
|
|
Accessories |
Power adapter, wall mounting bracket |
|
Other |
|
|
Mounting (options) |
1) Wall brackets for wall-mounting, VESA 100×100mm |
|
2) Metal desl stander to support the PC |
|
|
3) Open frame mount kits( left and right side) to hold the PC |
|
|
4) Embedded installation, 1 sets screws provided |
|
|
Certification |
CE, FCC |
|
Warranty |
1 year warranty |
