POWERFUL AND EFFICIENT THE HEAT DISSIPATION
The shell adopts an industrial-grade aluminum alloy circulating heat conduction system
LED HIGH-DEFINITION INDUSTRIAL CONTROL LCD SCREEN
Experience a visual feast by combining LED backlight technology with high-definition industrial control screens
IP65 SURFACE WATERPROOF DESIGN
The flat and seamless structure design prevents water droplets from entering the interior of the machine
Installation
Universal panel compatible for various mounting types
Application scenario
FAQ
1. Can you do OEM/ODM?
A: As a factory, we can customize the PC machine to your requirements.
1 pc is also welcome.
2. What warranty do you offer?
A: Each machine has a 3-year warranty, except for the human damage and force majeure factor.
Beyond the guarantee period machine, we will provide maintenance services and technical support.
3. Are you still worried about the compatibility of the PC with your software?
A: Before the order is confirmed, we could test if your software is compatible with our hardware, please kindly send us the software or TeamViewer.
4. Why should you buy from us and not from other suppliers?
A: 22 years of system manufacture experience, accepting OEM & ODM;
All products passed ROHS, CE, and FCC certification;
Quality is an enterprise's life, refuse low-quality items.
|
LCD panel( IPS screen) |
|
|
CPU |
Intel® Celeron J1900 2.0GHz, Quad cores, fanless |
|
Intel® Core i3-3217U 1.8GHz dual cores, with fan |
|
|
Intel® Core i5-3317U 1.7GHz dual cores, with fan, i5-6th |
|
|
Memory |
8GB DDR3 ( Max. 32G) |
|
Hard Drive Optional |
SSD: 32GB,64GB,128GB, 256GB |
|
HDD: 160GB,320GB,500GB,1TB |
|
|
Graphics |
CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
|
Audio |
Realtek ALC662, High Definition Audio (HD), Line in, Line out |
|
Network |
1×Realtek RTL 8111F Gigabit Ethernet controller |
|
Wifi |
Optional |
|
4G module |
Optional |
|
I/O Interface |
2×USB2.0, 2×USB3.0,1×Lan(RJ45),1 x COM(RS232/Serial), 1×VGA/HDMI/Audio OUT/POWER DC |
|
Opetation System |
Windows 7/8/10/Linux |
|
LCD panel |
|
|
Panel size |
7-21.5inch |
|
Resolution |
1280x1024,1920X1080 |
|
Brightness (cd/m²) |
350 cd/m² or custom |
|
Response time |
15ms |
|
Contrast ratio |
1000:1 |
|
View angle |
85°/85°/89°/89° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
10 points Projected capacitive touch |
|
Touch Interface |
USB |
|
Touch response time |
<8ms |
|
Luminousness |
75-85% |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V |
|
Working voltage |
DC 12V,9-36V Optional |
|
Power consumption |
≤30W |
|
Operating Environment |
|
|
Temperature range |
operating: -25 to 75°C, storage :-30 to 80°C |
|
Relative humidity |
5%~95% @ 40° C, non-condensing |
|
Vibration |
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
|
Packing Details |
|
|
Accessories |
Power adapter, wall mounting bracket |
|
Other |
|
|
Mounting (options) |
1) Wall brackets for wall-mounting, VESA 100×100mm |
|
2) Metal desl stander to support the PC |
|
|
3) Open frame mount kits( left and right side) to hold the PC |
|
|
4) Embedded installation, 1 sets screws provided |
|
|
Certification |
CE, FCC |
|
Warranty |
1 year warranty |
